Unicorn 11


  • Laser Module:Pure diodes, longer lifetime, higher reliability. Low divergence < 1.0 mrad(full angle).
  • Scanner:Pure ILDA control board, Safety key switch, Time delay for laser shooting, Emergence stop box(Time delay), Slide cover for beam aperture, Shutter, Scan-fail protection, Auto Power-Cut etc.
  • Features:Robust designed for medium sized venues and events. An optional integration of professional Grating Wheel offers an outstanding level of laser display.



  • Total laser power:                ≥ 11000mW
  • Diode -637nm:                    3000mW
  • Diode -525nm:                    4000mW
  • Diode -445nm:                    4000mW
  • Beam divergence:              <1.0mrad(full angle)
  • Modulation:                        100KHz Analog
  • Modulation way:                  linear analog modulation
  • Scanner type:                     PT-A40H
  • Scanning System:              30Kpps@8°
  • Scan angle:                        45°
  • Signal connector:               Ethernet,ArtNet,DMX,ILDA
  • Ingress rating:                    IP20
  • Temperature control:         TEC
  • Operatingtemperature:      -10℃-40℃
  • Dimensions:                      L361×W235×H185mm
  • Weight:                             12.5kg
  • Power requirements:        100-240V50/60Hz
  • Consumption:                   350W

Show Effect


Unicorn G 12w datasheet(英文版).pdf
