Venus 60（IP65）

Characteristic

  • Professional rainproof design system (IP 65), with high-end waterproof connectors and efficient cooling, Heatsink area covers 40% of the laser case area, Venus RGB60,000 performs greatly even under any extreme weather.
  • Ideal for long distance beam shows & basic graphics projections, seaside installations, landmark special lighting, and fountain special effect etc.
  • Build in Pangolin FB4 control interface with network switch for professional control and wiring.
  • Compliance: FDA/CDRH and CE.
  • Warranty: 24 months parts and labor.
  • Compliance: FDA/CDRH and CE.
  • Warranty: 24 months parts and labor.

Description

Specification:

  • Total laser power:                ≥ 60000mW
  • Diode -637nm:                    15000mW
  • Diode -525nm:                    20000mW
  • Diode -445nm:                    25000mW
  • Beam divergence:              <1.0mrad(full angle)
  • Modulation:                         100KHz Analog
  • Modulation way:                  linear analog modulation
  • Scanner type:                      PT-A25S
  • Scanning System:               25Kpps@8°
  • Scan angle:                         40°
  • Signal connector:                Ethernet,ArtNet,FB4-DMX
  • Ingress rating:                     IP65
  • Temperature control:           TEC
  • Operatingtemperature:        -10℃-40℃
  • Dimensions:                        L642×W493×H289mm
  • Weight:                                50kg
  • Power requirements:           100-240V50/60Hz
  • Consumption:                      2200W

Show Effect



datasheet

Venus RGB-62w datasheet
