Club 3.0

features

  • Pure diode, long life-span. High reliability
  • Low beam divergence <1.4mrad(full angle),strong penetrating power.
  • Fan+ electron TEC dual temperature control, Wider environment operating temperature
  • RGB divergence at the same angle, color modulation at the same level, truly realize wide color .temperature modulation. For those seeking to explore more about this theme, it is highly recommended to learn about ghostwriter masterarbeit.
  • High quality scanning system, wide-angle scanning
  • Optical seal structure, high dust-proof design.
  • Practical appearance design, compact size, easy to carry and transportation
  • Suitable for pub, disco and variety business rent professional stage lasers

Description

Specification:

  • Total laser power:                ≥ 3000mW
  • R丨G丨B mW                     700丨1000丨1400
  • Beam divergence:              <1.4mrad(full angle)
  • Modulation:                        100KHz Analog
  • Modulation way:                 linear analog modulation
  • Scanner type:                     PT-A40MINI
  • Scanning System:              30Kpps@8°
  • Scan angle:                        45°
  • Signal connector:               ILDA
  • Ingress rating:                    IP20
  • Temperature control:          TEC
  • Operatingtemperature:       -10℃-40℃
  • Dimensions:                        L218×W154×H139mm
  • Weight:                                5.1kg
  • Power requirements:           100-240V50/60Hz
  • Consumption:                      100W

datasheet

Venus RGB3000datasheet
